We are an ISO 9001:2015 Certified Company.

FAQ

The height of the racking system depends on the material handling equipment reach capacity.
A single rack with multiple loading levels is considered as one bay in a racking system.
Selection of racking systems is determined by various parameters, such as warehouse KPIs, space availability, SKUs specification, operations suitability, selectivity and stock rotation targets. STACK-IN Storage experts are fully-equipped do the free consultation and detailed analysis to answer all your queries.
In UDL system, the total material load is spread evenly across the entire area. (Totes, Bins).In Point Load, the total weight is concentrated on specific points in the area. (Pallet legs)rd of them accusamus labore sustainable VHS.
Pallet rack is customized as per customer requirements. At one loading level, it can take up to 4 tons. Check the feasibility for your operations with STACK-IN Storage experts.
STACK-IN Storage offers a wide range of decking options, like MS solid panels, perforated panels, punched panels, GI mesh decking, MDF decks, etc.
Yes, it is possible. As explained earlier, hybrid storage system can be designed and installed.
Yes, seismic zones play a crucial role in warehousing. Different zones require different tolerances and racking design. If your warehouse lies within a high seismic zone, check with STACK-IN Storage experts for more details specific to your project location.
Every STACK-IN Storage racking system is designed to take a specific load. You can check the same in the initial blueprint provided by us or in the load capacity signage boards. In case of non-availability or any mislaying of these, please confirm the weight with STACK-IN Storage.
Aisle requirement is determined by material handling equipment and SKU size. (Assumption: Standard Euro pallet)
Stacker: 2.8 to 3.0 mt.
Reach Truck: 3.0 to 3.4 Mt.
Double Deep Reach Truck: 3.2 to 3.6 mt.
Fork Lift Truck: 3.2 mt. to 4.5 mt.
Articulated Truck: 2.0 mt to 2.4 mt.
VNA: 1.8 mt. to 2.4 mt.
Racking base plates exert tremendous pressure on the floor below. A concrete floor can absorb this pressure. Care should be taken that the constructed floor can bear racking and material weight, and is also strong enough to anchor the storage racks.
For palletised loads, you can use STACK-IN Storage’s Drive In Racking or Shuttle Racking System. For smaller size SKUs/ items, you can select our multi-tier system. You can also have hybrid system of pallet racking and shelving for optimum storage and operations. For the best solution, get in touch with STACK-IN Storage experts.
STACK-IN offers one of the fastest installation services in the industry. The exact time can be calculated upon understanding the actual size of the project and your on-going operations. Before commencing installation, STACK-IN project management experts will provide a project execution chart that has been created in collaboration with the customer’s needs. We try and ensure minimum disruption in on-going warehouse or manufacturing operations.
STACK-IN Storage’s customized solutions in pallet racking and shelving such as multi-tier system enables you to use most of the height available in your warehouse and the Maximum Fork Height (MFH) of your material handling equipment.
The prices vary depending upon the exact solution offered to our customers. Every project is customized to best suit the customer storage and operational requirements, hence, it is difficulty to arrive at the standard price. Contact STACK-IN Storage experts for an accurate estimate.
Regular racking inspection helps identify components which need to be repaired or replaced. It gives a detailed report of rack or shelf damage and fitment issues. It is an excellent way to identify any safety breach and prevent accidents.
Your warehouse should conduct rack inspection every 4 to 6 months. In case you notice any physical damage, the rack material should be unloaded and discarded immediately. Report the incident to racking system suppler.
No, it is not. However, it is advised to get your racks inspected regularly for safe and better warehouse operations.
